The MULTIPOINT Doppler sensors are tailor made for the MULTIPOINT dimmable fluorescent lighting ballasts.

Welcome at the MULTIPOINT sensor page

MULTIPOINT has combined the Doppler and Radar technology in a very compact sensor. This fully hidden MULTIPOINT sensor detect the motion of an object at a certain speed and give an output signal to archieve the desired function, f.i. the controll of a lighting fixture.

The MULTIPOINT Doppler sensors are tailor made for the MULTIPOINT dimmable fluorescent lighting ballasts. The output wires of MULTIPOINT Doppler sensors can be up to 2 kilometer long without function loss, voltage drop and EMC interference.

The combination of the MULTIPOINT high frequency ballasts and MULTIPOINT Doppler sensors forms an ideal solution for every small and large lighting installation.

It is possible that one or more MULTIPOINT sensors controll a lighting installation who is divided over 3 power lines (L1, L2 and L3) as long as all MULTIPOINT sensors have the same power line (L1) and neutral (N) as power supply.

The maximum Ohmic switchable load for the MULTIPOINT Doppler motion sensor is 1000 W (f.i. incandescent bulbs) or Inductive 400 W (fluorescent lamps).

This load could be bulbs inside the lamp and also additional / external lamps. However, when the MULTIPOINT Doppler motion sensor is used together with the special MULTIPOINT dipswitch ballasts, the load is nearly unlimited.

Mechanics of the MULTIPOINT Doppler motion sensor:

Casing of the MULTIPOINT Doppler motion sensor:
The MULTIPOINT Doppler motion sensor is provided as a compact PC box. The size of the casing is approx. 98 x 51 x 26 mm including the mounting lips.

Mounting of the MULTIPOINT Doppler motion sensor:
If the MULTIPOINT Doppler motion sensor is mounted in the luminaire, please consider the following points:

The MULTIPOINT Doppler motion sensor must be mounted flat on the base plate of the luminaire, providing a detection field rectangular to the base plate.

Any metal parts in front or beside the MULTIPOINT Doppler motion sensor can change the detection field in size and shape.

The MULTIPOINT Doppler motion sensor must not be mounted close to the light bulb (maximum operating temperature is 70°C).

The best position for the MULTIPOINT Doppler motion sensor is below the bulb.

Vibrations of the MULTIPOINT Doppler motion sensor must be avoided.

No light tight parts must shade the daylight sensor of the MULTIPOINT Doppler motion sensor. A fiber optic is included to allow the end users to stretch the fiber optic outside the luminaire, to the position and direction desired.

Enclosed in our special designed IP54 housing, the MULTIPOINT Doppler motion sensor is completely protected against any harmful deposits of dust and water splashing from any direction, which makes it possible for outdoor use. The cover of this IP54 box is on demand made of clear or light tight Poly-Carbonate (PC)

Note: snow, storm and falling leaves do not activate the sensor.

Tips for installation of the MULTIPOINT Doppler motion sensor:

1. When the MULTIPOINT Doppler motion sensor is mounted in a luminaire, or other compartment where the surrounding is very dark, it is recommended to insert the fiber optic (included in the package) in the MULTIPOINT Doppler light sensor hole, to direct the outside light into the MULTIPOINT Doppler motion sensor when the detection of outside light is needed.

2. If the MULTIPOINT Doppler motion sensor is activated / interfered by motion of the people or moving object next door, please reduce the sensitivity, or adjust the direction of the MULTIPOINT Doppler motion sensor.

3. The detection angle and distance is closely related to sensitivity. Fine-tune the sensitivity switch program to fit your specific application.

5 Technical Data of the MULTIPOINT Doppler motion sensor:

Power:
Operating voltage: 220-240V +/- 10%, 50/60 Hz, 100-127V+/- 10% on request
Switched power: 1000 W (light bulbs) or 400 W (fluorescent lamps)
Energy consumption: 0.6w (in standby) or 1.2w (when in operation)
Interface: 3 pole pluggable terminal block (N, L, L') for 1.5 mm² cable


Sensor principle of the MULTIPOINT Doppler motion sensor: Doppler type motion detector
Detection frequency 5.8 GHz +/- 75 MHz
Detection wave power:
For the Standard version: <1mw
For the Reinforced version: <2mw

Detection range of the MULTIPOINT Doppler motion sensor:
Standard version: 11m.
Reinforced version: 22m (at max. sensitivity)

Detection angle of the MULTIPOINT Doppler motion sensor:
30--150° (depending on sensitivity and height)

Motion speed detection of the MULTIPOINT Doppler motion sensor:
1-20km/h (<3m mounting height);
1-200km/h (>5m mounting height)

Adjustable functions of the MULTIPOINT Doppler motion sensor:

Sensitivity of the MULTIPOINT Doppler motion sensor:
20 / 30 / 50 / 75 / 100%, can be customized by the user.

Hold time of the MULTIPOINT Doppler motion sensor:
5s/30s/180s/300s/15min/25min, can be customized by the user.

Daylight sensor of the MULTIPOINT Doppler motion sensor:
daylight / twilight / darkness (can be customized by the user)

Operating conditions of the MULTIPOINT Doppler motion sensor:

Mounting height of the MULTIPOINT Doppler motion sensor:

Standard version of the MULTIPOINT Doppler motion sensor:
max.5m (wall mounting), max.11 m (ceiling mounting)

Reinforced version of the MULTIPOINT Doppler motion sensor:
max. 8m (wall mounting), max.22m (ceiling mounting)

Operating temperature of the MULTIPOINT Doppler motion sensor:
-20 till +70°C

IP rating of the MULTIPOINT Doppler motion sensor:
IP20 (if not mounted in a luminaire or box) or IP54 (when mounted in the MULTIPOINT special outdoor box)

Product Specification of the MULTIPOINT Doppler motion sensor:
MULTIPOINT Doppler motion sensor.

6 Compliance and Marking of the MULTIPOINT Doppler motion sensor:
The MULTIPOINT Doppler motion sensors are compliant to the following European directives and standards:

Harmonized standards valid for the MULTIPOINT Doppler motion sensor:
IEC61000-4-2 IEC61000-3-2
IEC61000-4-3 IEC61000-3-3
IEC61000-4-4 EN60669-2-1
IEC61000-4-5 EN60669-1
IEC61000-4-6 CISPR 14
IEC61000-4-8 CISPR 15
IEC61000-4-11

Marking of the MULTIPOINT Doppler motion sensor:
The MULTIPOINT Doppler motion sensors are marked with the following conformity marks:

EU directives:
Nr. 1999/5/EC EU Directive on radio equipment and telecommunications
Nr. 89/336/EEC EU Directive on Electromagnetic Compatibility
Nr. 73/23/EEC EU Low-Voltage Equipment Directive
Nr. 2002/95/EC EU Directive on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS)
CE compliance, declares the compliance to the above mentioned standards

Quality Certificates of the MULTIPOINT Doppler motion sensor:
Semko certificate
Chinese safety standard

MULTIPOINT is specialized in the invention and production of high quality electronic lighting ballasts, sensors and transformers.

MULTIPOINT have a highly specialized production facility available.

MULTIPOINT offers a wide range of high quality electronic lighting ballasts, sensors and transformers for large and small OEM's, wholesalers, installers, contractors, etc.

MULTIPOINT delivers you high quality electronic lighting ballasts, sensors and transformers directly from the factory in China or via your local distributor. See our DISTRIBUTORS page for your nearest distributor.

MULTIPOINT is happy to delivers you also samples for examination, testing and evaluation in your lighting projects and products. See our SAMPLES page for more information.
